Mixer ACS RV-32

Thông số kỹ thuật: Mixer ACS RV-32

32 channel signal input (24 channel mic, 3 groups of stereo, 1 group of digital input: sound card /mp3+ optical fiber)
• Each input channel has built-in pressure limiter, noise gate, high-low pass, 4-segment parameter equalization, time delay, channel sound and image balance adjustment
• MIC input adopts digital gain adjustment
• +48v phantom power supply (MIC channel is turned on and off independently)
• Built in 12 9-segment graphic equalizers (1-24 input channels can be inserted arbitrarily)
• Input / output EQ on/off
• Stereo return input
• Fast copy function of channel parameters
• Each channel is equipped with multi-function menu, mute button and monitor button
• Each channel is equipped with 100mm electric pushers, signal lights and peak lights (22 electric pushers)
• 12 channel signal output (stereo main output, 8-Channel marshalling output, 2-channel auxiliary output)
• Processing of each output channel: high-low pass filtering, 15 segment parameter equalization, compressor, delay, phase
• Auxiliary output (before and after the pusher)
• Stereo digital recording function
• Double row 3-color 12 segment level indicator
• Built in sound card (MP3, Android, PC direct playback, recording)
• Four quick scenario call modes and 20 scenario storage
• Storage and call of user parameters (can be managed on PC)
• Built in 4 independent DSP effectors
• 7-inch 1024*600 HD touch color screen
• FX pedal switch interface
• optical fiber input and output
• Chinese and English switching display of multi operating system control software (IOS system, Android system, windows system)
• support wired network port adjustment (or external router wireless adjustment)
• the user can customize the layer and output the mixed editing function
• parameter locking function
• two layers of page turning, which simplifies the operation and is more convenient to use
